DrafSync Detailing Services Pvt Ltd Circular Emblem
DrafSync

Detailing Services Pvt Ltd

Built On Accuracy. Driven By Expertise.
🇺🇸
Serving U.S. Steel Fabricators Erectors & General Contractors Nationwide
WhatsApp Email Get Quote
FAST TURNAROUND: 24-48h RFQ & expedited shop deliveries
ACCURATE & RELIABLE: AISC, AWS & NISD Code Compliant
COMPETITIVE PRICING: Per-ton or hourly contract rates
QUALITY ASSURED: 4-Step Multi-Level QC Verification
CONFIDENTIAL & SECURE: Strict NDA & secure file transfer
AISC CERTIFIED STRUCTURAL STEEL DETAILING PARTNER

High-Precision Steel Detailing & Take-Off
For American Steel Fabricators & Erectors

Engineered for zero-error shop fabrication and seamless field erection. We furnish fully coordinated 3D models, fabrication-ready shop drawings, erection plans, open web joists & metal decks, CNC DSTV/DXF packages, and accurate MTOs conforming strictly to AISC, AWS, NISD, SJI, and SDI standards.

U.S. Time-Zone Overlap & Dedicated Project Lead
LOD 400 Fabrication & CNC Machine Feed Files
Steel Joist (SJI) & Floor/Roof Deck (SDI) Layouts
Strict 4-Step Quality Control (QC) Engineering Review
Explore 12 Detailing Disciplines 4-Step QC Process
AISC Certified
Detailer

AISC Certified Detailers

Strict adherence to AISC Code of Standard Practice

Our detailing engineers hold active AISC credentials ensuring every beam, column, moment connection, baseplate, and deck schedule is fabrication-ready with zero field rework.

Primary Domain: www.drafsync.com
RFQ Desk Email: [email protected]
Direct / WhatsApp: +91 9836347069
Zero-Error Engineering Protocol

Our 4-Step Quality Control (QC) Checking Process

Every project delivered by DrafSync passes through a rigorous four-phase verification cycle before any release is dispatched to fabricators or shop machines.

PHASE 01 1

Model Audit & Clash Resolution

Deep 3D model auditing in Tekla/SDS2 against architectural and structural design prints before sheet extraction.

  • Strict grid offsets, building elevations & member geometry verification.
  • Collision detection between structural members, gussets, and anchor rods.
  • MEP / HVAC clearance check against architectural drawings and duct models.
Gate: Model Lockdown
PHASE 02 2

Connection & Code Compliance

Verification of all connection designs against contract calculation sheets and governing engineering codes.

  • Conformance with AISC 360, AISC 341 (Seismic), and AISC 358.
  • Bolt shear, bearing capacities, edge distances, and hole gauge validations.
  • Complete AWS D1.1 weld sizes & SJI / SDI joist/deck attachment compliance.
Gate: Structural Code Sign-off
PHASE 03 3

2D Drawing Back-Checking

Independent senior checker audits all extracted fabrication assemblies, single parts, and erection plans.

  • Red-line back check of dimension strings, copes, bevels, and camber marks.
  • Piece mark uniqueness, erection sequence IDs, and shipping package tags.
  • Bill of Material (BOM) cross-check against structural model weights and grades.
Gate: Redline Resolution
PHASE 04 4

Lead Sign-Off & NC Validation

Final sign-off by Project Lead Engineer and automated machine tooling simulation prior to fabricator delivery.

  • NC1 / DSTV drill and punch path validation for CNC machinery.
  • KISS / FabSuite file generation with matching shipping sequences.
  • Official DrafSync Detailing QC stamp and transmittal documentation.
Gate: Ready For Fabrication (RFF)
Comprehensive Detailing Deliverables

Our Specialized Steel Detailing Services

Click any discipline below to Inspect Technical Specs & Deliverable Formats.
1 MTO Report

Steel Take-Off

Accurate Quantity Take-Off & Detailed Advance Bill of Material (ABM) Reporting for bidding & mill order planning.

Inspect Specs
2 Shop Ready

Structural Steel Shop Drawings

Fabrication-Ready single-part and assembly shop drawings with complete weld, cope, and hole callouts.

Inspect Specs
3 Field Erect

Erection Drawings

Clear & precise erection plans, elevations, sections, and field installation markups for quick assembly.

Inspect Specs
4 Foundation

Anchor Bolt Plans

Accurate foundation setting plans, anchor bolt layouts, embed plates, templates, and baseplate details.

Inspect Specs
5 BOM / KISS

Bill of Materials (BOM)

Material list with weights, surface areas, grades, field bolt lists, and shipping summary manifests.

Inspect Specs
6 PE Stamped

Connection Detailing

Detailed shear, moment, and bracing connections fully compliant with AISC 360 and AISC Manual 15th/16th Ed.

Inspect Specs
7 LOD 400

3D Steel Modeling

Accurate 3D modeling for coordination and visualization with exact bolt, clip, and cope geometry.

Inspect Specs
8 SJI & SDI

Joist & Deck Detailing

Open web joists, joist girders, metal deck layouts, bridging schedules, pour stops, and SJI/SDI compliance.

Inspect Specs (SJI / SDI)
9 CNC Direct

CNC / DXF / DSTV Preparation

Direct automated drill, punch, plasma & saw files (NC, NC1, DXF) configured for automated shop machinery.

Inspect Specs
10 Navis Clash

BIM Coordination

Multi-disciplinary clash detection, IFC model exchange, MEP clearance checks, and Navisworks audits.

Inspect Specs
11 Zero Delay

RFI & Revision Control

Timely responses, cloud revision tracking, cloud delta clouds, and complete drawing issue history control.

Inspect Specs
12 Final Closeout

As-Built Drawings

Post-erection modification integration, field revision incorporation, and complete project closeout sets.

Inspect Specs
Proven Value Delivery

WHY PARTNER WITH US?

Built to act as an agile, in-house extension of your detailing department.

Experienced & Skilled Detailing Team

Over a decade of U.S. industrial, commercial, and miscellaneous steel detailing experience.

Accurate Take-Offs & Material Reports

Milestone-level material estimates minimize scrap and ensure competitive fabricator bidding.

Fabrication-Ready & Code Compliant Drawings

Adhering strictly to AISC 360, AWS D1.1 structural welding, and OSHA erection safety guidelines.

Strict 4-Step Quality Control & Back-Checking

Model auditing, connection checking, drawing back-checking, and final lead engineer sign-off.

Fast Turnaround & On-Time Delivery

Time-zone advantage allows overnight turnarounds on RFIs and drawing packages.

Flexible Engagement Models

Fixed project price, per-ton detailing rates, or dedicated monthly detailer retainer models.

Confidential & Secure Data Handling

Enterprise file transfers, encrypted cloud storage, and binding Non-Disclosure Agreements.

Cost-Effective Solutions

Maximize fabricator gross margin without sacrificing drafting precision or AISC compliance.

Fast Quote Generator

HAVE A PROJECT? SEND US YOUR DRAWINGS!

PDF Drawings
DWG / CAD
IFC Models
Revit RVT
150 Tons
10 Tons (Misc/Stairs) 500 Tons (Standard Frame) 2,500+ Tons (Heavy Industrial)
Estimated Detailing Delivery Window: 1.5 - 2.5 Weeks

Or email sets directly to [email protected] with subject "New Project Drawing Set".

Advanced CAD & BIM Ecosystem

SOFTWARE EXPERTISE

A
AUTOCAD 2D & GA Plans
SDS/2
SDS/2 Intelligent 3D
SP
STEEL PROJECTS Shop Automation
R
REVIT BIM Exchange
N
NAVISWORKS Clash Detection
FAB
TEKLA POWERFAB MIS & Production
Trusted Globally Long-term fabricator partnerships
100% Dedicated Direct account engineer assignment
On-Time Delivery Strict project schedule adherence
Quality & Safety Zero error fabrication commitment
